Structural Composition

The main components of dry type transformer are listed as follows:

1. Iron CoreLaminated silicon steel sheets form the magnetic circuit of the transformer, featuring low magnetic loss.

2. WindingsHigh-voltage primary winding and low-voltage secondary winding adopt epoxy resin casting insulation without insulating oil.

3. Frame & HousingHigh-strength steel enclosure with ventilation structure, protecting internal windings and iron core.

4. Cooling FanAuxiliary air cooling component to accelerate heat dissipation of windings under heavy load.

5. Insulating SupportHigh insulation grade support blocks to fix windings and ensure safety clearance.

6. Temperature Monitoring DeviceBuilt-in temperature sensor and thermometer to real-time monitor winding operating temperature.

7. Other Auxiliary PartsIncluding high/low voltage insulating bushings, base bracket, grounding device, control cabinet and other accessories.

Operating Principle

Dry type transformer works on the law of electromagnetic induction.After alternating current passes into the primary winding, alternating magnetic flux is generated and conducted through the iron core. The alternating magnetic field induces electromotive force on the secondary winding to complete voltage transformation. Different from oil-immersed transformers, it relies on air convection and fans for heat dissipation, with epoxy resin as the main insulating medium.

Advantages

1. Safe and fireproofNo flammable insulating oil, greatly reducing fire risk, suitable for indoor dense public places.

2. Low operation noiseCompact fixed winding structure with small vibration, stable low-noise operation.

3. Simple maintenanceOil-free design eliminates oil replacement, oil leakage and oil detection work, reducing maintenance cost.

4. Eco-friendly & cleanNo oil pollution, no harmful gas volatilization, clean and environmentally friendly.

5. Wide installation adaptabilityCan be directly installed indoors without independent transformer room, small floor space.

Application Areas

1. Urban commercial power distributionShopping malls, office buildings, residential districts, underground pipe galleries and subway stations.

2. Industrial manufacturing workshopsChemical plants, food factories, data centers and other fire-sensitive production sites.

3. Public and special facilitiesHospitals, schools, power stations, high-voltage test rooms and new energy supporting projects.
